Modulatis™, Modular Lattice Screening

Modulatis is a modern take on lattice, with a choice of lattice squares that fit within a hardwood grid. The modular components ship in regular boxes, and assembly is simple.

Where to use Modulatis Panels.

  • Attach to the top of a board fence to create a fence topper.
  • Insert into a fence to create a view window.
  • Link together in a site-built frame to create a larger fence or screen.
  • Display against the wall as a trellis or frieze.
  • Use on a roof deck to block neighbors.
  • Hide unsightly trash cans or HVAC/pool equipment.

Modulatis Features

  • Two configurations, the base product MBS is frameless. MFR includes an optional frame.
  • Completely reversible - both sides are equally good.
  • Align pattern lines from adjacent panels to create an Arabesque effect.
  • Add Landscape posts for free standing / fencing solutions.
  • Ships in standard boxes for easy staging and cheaper shipping.

Modulatis Installation and Hardware Options

  • Wall mount hardware with pre-drilled holes, stainless steel screws and stand-offs maximize shadow play.
  • Optional Landscape Posts for free standing applications.
  • NONE of the products sold on this site are rated for structural applications such as railings. Call for custom railing and other structural applications.

Technical Info: Dimensions and Profile

  • Dimensions: each square is 16". And screens can be up to 80" in width and height.
  • Grid is 1.125 deep x 0.625 wide.
  • Profile: Most patterns use sticks that are 3/4" face and 11/2" depth, with smallest opening 21/4" (profile 3-6-3).

Technical Info: Woods Species

  • Exterior softwood: Our standard wood specie is western red cedar, a light strong, stable, North American softwood with a range of orange-red-brown colors. It contains natural acids that defend against microbial and insect decay, but like most softwoods, can be dinged and dented.
  • Exterior hardwood:, we use a sapele, which has many of the same visual qualities and colorings as African mahogany. It is strong and stable, and holds up better for high usage applications such as front gates.
  • Interior woods: In addition to cedar and sapele, we can fabricate in most common species including walnut, white oak, and poplar for paint grade applications. Call for pricing and additional species.
  • Call for FSC woods for green projects.
  • Download Species and Finishing Guide

Technical Info: Finishes

We offer three factory applied finishes. Call for custom finishes.

  • Penetrating oil - We use a custom tinted oil manufactured by Penefin, that is zero VOC and is equally good for interior or exterior applications. Old Growth Oil (OGO) tint accentuates the oranges-reds-browns of both cedar and sapele to create a deep, rich, woody color. Can be maintained with re-application of any oil based product. Interior or exterior.
  • Base stain - We offer a translucent stain in both gray and black. The stain does not have the durability of the two step stain, but is perfect for those who want a transition to a natural weathering look. Exterior only.
  • Two step - a tinted glaze is added to the base stain for greater durability and easier maintenance. Available in stock gray and black, a range of custom colors is also avaialble.
  • Penetrating oil - We use a custom tinted oil manufactured by Penefin, that is zero VOC and is equally good for interior or exterior applications. Old Growth Oil (OGO) tint accentuates the oranges-reds-browns of both cedar and sapele to create a deep, rich, woody color. Can be maintained with re-application of any oil based product. Interior or exterior.
  • Base stain - We offer a translucent stain in both gray and black. The stain does not have the durability of the two step stain, but is perfect for those who want a transition to a natural weathering look. Exterior only.
  • Two step - a tinted glaze is added to the base stain for greater durability and easier maintenance. Available in stock gray and black, a range of custom colors is also avaialble.

Technical Info: Lattice Construction

  • Lattice connections are generally a half lap secured with a blind hardwood dowel and waterproof glue. The half lap creates a decorative joint contrasting stick and and grain and face grain.
  • Lattice is secured within a perimeter frame using mortise and tenon joinery.
  • Our patented Pinlock™ joinery uses a pair of pins to secure the joint securely without the need for glue or mechanical fasteners. It is used for structural railing panels and also DIY kits.
  • Our joinery allows a lifetime of durability in challenging exterior environments.
  • NONE of the products sold on this site are rated for structural applications such as railings. Call for custom railing and other structural applications.

Shipping Ordering, and Lead-times

  • Depending upon the size and location, LatticeStix has three delivery methods:
    • Small items - For items' whose area is less than 16 square feet, we use Ground Delivery services such as FEDEX Ground.
    • Large items - For items over 16 square feet, irregular sizes, gates, or large quantity of smaller items, we use LTL shippers such as YRC. LTL shipments require palletization / crating services.
    • Local Delivery - If you are within 50 miles of our facility in San Francisco, we use local courier companies.
  • LTL shipping may have additional fees for residential delivery, lift gate, and other special services. Call for details.
  • In the event of damage, photograph and retain packaging, photograph damage, and contact sales@latticestix.com.
  • Products in the online catalog ship in 3- 6 weeks. You will receive an online notice after ordering confirming the estimated ship date. This date is an estimate only.
  • Custom products ( pattern / size / other ) ship in 6-10 weeks. Estimate dates will be provided once payment is received.
  • Ready-to-ship items will indicate on the applicable web-site the shipping time-frame.
